24 VAC DPDT General Purpose Switching Relay For HVAC Systems And Electrical Installations, Controls Fan Motor In Air Handler, Two Terminal Sets 1 2 3 And 4 5 6, Replaces APSR 340

24 VAC DPDT HVAC Relay for Fan Motor Control (1 Pack)
✔️ 24V coil, DPDT with two NO contact sets 1-2-3 and 4-5-6

This 24 VAC DPDT general purpose switching relay is designed to control the fan motor in the air handler portion of HVAC systems. It can also be used for other low-voltage switching tasks across electrical panels and equipment.

✅ 24 VAC coil
✅ DPDT with two NO contact sets: 1-3 and 4-6
✅ Ratings: 12 FLA 60 LRA at 125V; 6 FLA 35 LRA at 250V
✅ Replaces part numbers: 92340, JFR340, RBM 90-340, 90-340, 90340, APSR-340
✅ Universal replacement for matching specs in HVAC fan and related loads

💡 What is a 24V DPDT switching relay used for in HVAC and electrical panel wiring? This handy device controls two circuits from a single control line. - It provides two independent switched paths - It supports a 24V coil and standard line voltages - It simplifies replacements when upgrading or repairing HVAC relays
